Blackmagic ATEM Micro Camera Panel

Computer Interface

USB Type‑C.

Bluetooth

Bluetooth 5.1 LE

Software Updates

1 x USB‑C for firmware updates.

Camera Selection buttons

8 x NKK buttons.

Assignable via setup utility.

Camera Number Display

Green off air, red on air.

Setup

White and black balance setup.

Flare via modifier key.

3 Axis Joystick

1

Preview Button

1

Iris Control

Auto Iris On, Coarse control.

Iris Range

CLS f32 to f1.2

Gain Range

-12dB to +32dB

ND Filters

0, 2, 4, 6.

Shutter Range

1/24 to 1/2000

White Balance Range

2500K to 10,000K

Recallable Scenes

5 per camera.

Panel Active

Protects settings.

Software Applications

ATEM Micro Panel controls ATEM Software Control Panel running on the host computer.

Power Supply

Internal battery with power switch.

USB-C port for external power supply and battery charging.

Power Usage

TBA

Battery Life

TBA

Operating Temperature

5° to 40° C (41° to 104° F)

Storage Temperature

-20° to 45° C (-4° to 113° F)

Relative Humidity

0% to 90% non‑condensing
